A Range of Fixings Suitable for Celcon Standard and Hi-Strength Aircrete Blocks

Sponsored by H + H CelconAug 11 2006

Manufacturer Telephone No:	Type of Plug		Screw Size	Minimum Screw Penetration (mm)	Individual Fixing Ultimate Pull-out Force (N)
	WOOD SCREWS driven direct	(no plug)	No.10	37	870
PLASPLUG 0141 638 7961	Plastic	Heavy Duty	No.10	57	950
RAWLPLUG 0141 638 7961	Fibre Rawlbloc (Lightweight Block Fixing)	8 x 50	No. 8	38	1110
		Small (8)	5 mm	68	730
		Large (10/65)	6 mm	78	1200
UNIFIX 01763 244 111		LB55/10 mm	No. 10	70	1450
UNIFIX 01763 244 111		LB70/10 mm	No. 10	85	3600
FISCHER 01491 833 000	Nylon	S6	No. 10	35	800
		S8	No. 12	46	1300
		S10	No. 14	57	2400
		GB8	5 mm	45	2700
UPAT TURBO 01189 574 575	Nylon	K4	4mm	35	1000
	Nylon	Related Stories Celcon Aircrete Flooring System - Fast Cost Effective Ground Floors The Story of Seabright Street – A Brighter Future from H+H Celcon Thin-Joint System and EcoHomes Assessments K8	8 mm (coach screw)	45	1600
	Metal fire resistant)	M6	6 mm	20	2000
		M8	8 mm	25	2600
		M10	10 mm	30	2800

Approximate equivalent screw sizes: No.8: 4 mm; No.10: 5 mm; No.12: 5.5 mm; No.14: 6 mm; No.16: 7 mm

Nailed Fixings

	CUT NAILS	driven direct	75 mm	55	1150
HELIFIX 020 8735 5200	TurboFast			100	970
LODEN 01527 68559	Anchor		HA75	56	1050
			HB90	56	1650
	SD Heavy Duty (Especially useful for handrail fixings)			-	4500

Notes

1. The diameter of holes drilled in the blocks should be such that the plugs fit tightly prior to the screws being driven.

2. The size and length of a fixing should be suitable for the block thickness.

3. Generally, fixings should be spaced from each other (and from the free edge of a block when this is applicable) at a distance not less than the depth of penetration of the fixings into the block, but this should be confirmed with the fixing manufacturer.

This information has been sourced, reviewed and adapted from materials provided by H + H Celcon.

For more information on this source, please visit H + H Celcon.
